MUTOH ValueCut VC2-1300 - Page 29

MAINTENANCE MANUAL
VC2E-MM-00
29
6. Make a space between the rollers as shown
in the figure above.
You can loosen the bolt easily by putting your fingers
between the rollers.
7. Remove the roller under the cursor from the
rail, and then remove the cursor.
Install the tool carriage in the reverse order of removal.
Be careful not to drop off the spacer when
removing the roller.
