MUTOH ValueCut VC2-1300 - Replacing Main Board

MAINTENANCE MANUAL
VC2E-MM-00
32
Replacing Main Board
Please follow the steps below to replace the main board.
1. The main board is installed at the right
end.
2. Remove the 5 cables and 4 screws.
1: Install the Main board in the reverse order of
removal.
2: Need to remove the X-motor first to remove the
screws on the main board.
3. Remove the main board.
