MUTOH ValueCut VC2-1300 - Replacing Driver Board

MAINTENANCE MANUAL
VC2E-MM-00
33
Replacing Driver Board
Please follow the steps below to replace the driver board.
Main 基板を交換します。
1. The driver board is installed in the
middle.
2. Remove the 10 cables and 4 screws.
3. Remove the driver board.
Install the Driver board in the reverse order of
removal.
