MUTOH ValueCut VC2-1300 - Replacing Pinch Roller Sets

MAINTENANCE MANUAL
VC2E-MM-00
24
Replacing Pinch Roller Sets
Please follow the steps below to replace the pinch roller sets.
1. Lower the lever.
(Reference: Pinch rollers are down)
4. Lift the Top cover vertically to remove.
(Reference: Pinch rollers are up)
Make sure not to damage the sensor-flag when lifting
the Top cover.
