MUTOH ValueCut VC2-1300 - Replacing Power Supply Board

MAINTENANCE MANUAL
VC2E-MM-00
34
Replacing Power Supply board
Please follow the steps below to replace the power supply board.
1. The power supply board is installed at
the left side.
2. Remove the 2 cables and 4 screws.
3. Remove the power supply board.
Install the Power supply board in the reverse
order of removal.
