Specification
Model Number
VC2-600
VC2-1300
VC2-1800
Operation Method
Paper Moving Type
Max. Cutting Width
610mm(24in)
1320mm(52in)
1830mm(72in)
Max. Cutting Length
50m(164ft)
Max. Media Loading Width
770mm(30.3in)
1594mm(62.7in)
1990mm(78.3in)
Min. Media Loading Width
50mm(1.97in)
300mm(11.8in)
Number of Pinch Rollers
3
4
6
Acceptable Material Thickness
0.8mm(0.03in)
Drive Motor
DC Servo Control
Cutting Force
5~600 g
Max. Cutting Speed
1530 mm/sec
Max. Acceleration
4.2 G
Blade Offset
0~1.0 mm (0.025mm/step)
Memory Buffer
32 MB/16MB (when using AAS)
Interface
USB 2.0 (Full speed), Serial (RS-232C) and Ethernet
Type of Command
HP-GL, HP-GL/2
Mechanical Resolution
0.006mm
Software Resolution
0.025 mm
Distance Accuracy
±0.254 mm or ±0.1% of move, whichever is greater
Repeatability
±0.1mm
Curve & Arc Smoothing
Yes
Configurable Origin
Yes
Test Cut capability
Yes
Tangential
Yes
Repeat
Yes
Copy
Yes
Pouncing
Yes
Automatic-Aligning System
AASII
Control Panel
LCD (20 digits x 2 lines), 14 keys, 1 Power LED
Power Supply
AC 100-240V, 50~60 Hz (Auto switching)
Power Consumption
110 W
Dimension (HxWxD) mm
412 * 950 * 486
1111 * 1774 * 651
1127 * 2170 * 756
Net Weight
18 kg
50 kg
63 kg
Stand
Optional
Standard
Media Basket
Optional
Standard
Operation
Environment
Temperature
15 ﾟ C ~ 30 ﾟ C, 60 ﾟ F ~ 86 ﾟ F
Humidity
25% ~ 75%
 The specification and data sheet may vary with different materials used. In order to obtain the best
output quality, please maintain the machine regularly and properly.
 MUTOH reserves the right to change the specifications at any time without notice.
 The above listed specification values are effective only when operated with media certified by
MUOTH.
