Diagnostic Test for SRAM and DRAM
This test provides the ability to diagnose the SRAM and DRAM. If these two components are bad, replace
them. Otherwise the cutting plotter will not work properly.
Diagnostic Test for Lever Sensor
It diagnoses the lever sensor. If the sensor is faulty, the cutting plotter cannot sense if the pinch rollers
have been lowered or not. If the lever sensor is down, the LCD displays “DOWN”. If the lever sensor is up,
the LCD displays “UP”. To return to the previous menu, Press the ON/OFF LINE key.
ENTER key
ON/OFF LINE key
or
Lever sensor
