Cleaning 129
Cleaning period:
•Weekly
Preparation:
• Cleaning stick
Cleaning around the capping unit
Important!
During cleaning, please note the followings.
• Use a dry cleaning stick. A damp stick can cause damage to the print head.
• Do not touch the tip of a cleaning stick with fingers. Skin oil will damage the print head.
• Do not reuse a cleaning stick. Dust on the stick will damage the print head.
• This cleaning takes about 5 minutes. If it takes longer, the stick will get dry causing damage to the print head.
[1]
Put the printer into the CR maintenance mode.
"Putting the printer into the CR maintenance mode" P. 126
[2]
Open the front cover.
[3]
Open the maintenance cover on the right side.
[4]
Use the cleaning stick to clean around the rubber part of the capping
unit to remove the ink deposits and dust.
Capping unit: 2
If it is hard to remove the stain, perform “Short” Head cleaning, and then
clean again.
DO NOT touch the absorber (yellow)
Clean this part (grey)
To Next Page
