28 Loading a roll media
[6]
While one person holds the front edge of the media, the other person turns the flange to slightly rewind the media
onto the roll to remove warp or skew.
If you remove your hands from the front edge of the media while rewinding, the media can be removed from the media slot.
[7]
Check that the right-hand edge of the media is located at the left side of the media guide line.
If not, print quality can be affected.
[8]
If needed, use a slide lock lever on the pressure rollers to individually cancel or reduce the holddown pressure.
"Canceling or reducing pressure rollers individually" P. 41
Note
Normally you do not need to adjust the holddown pressure by the slide lock levers.
To print on thin or soft media, individually reduce the holddown pressure.
To Next Page
