MV-1 PT019021 - Page 147

Roadside Emergencies 145
SMART JUNCTION BOX
FUSE/RELAY
LOCATION
FUSE AMP
RATING
PROTECTED
CIRCUITS
1 30A Not Used
2 15A Not Used
3 15A Not Used
4 30A Not Used
5 10A SPDJB micro,
Brake Shift Interlock
6 20A Turn Signals/Hazards/Stop Ips
7 10A Left Low Beam
8 10A Right Low Beam
9 15A Courtesy Lights
10 15A Cluster/Panel Illumination
11 10A Not Used
12 10A Not Used
13 5A Exterior Power Mirrors
14 10A Not Used
15 10A Not Used
16 15A Not Used
17 20A Power Door Locks
18 20A ABC VBAT 2 Rear Wiper,
Rear Washer, Liftgate Latch
19 25A Not Used
20 15A Diagnostic Conn Power
21 15A Not Used
22 15A Parking/License Lights
23 15A High Beams
24 20A Horn
25 10A Not Used
26 10A Cluster (Battery)
27 20A Ignition Switch Feed (Battery)
28 5A Not Used
29 5A Cluster (R/S)
30 5A Not Used
31 10A Not Used
32 10A Restraints Module (R/S)
33 10A Not Used
34 5A ABC Module (R/S)
SMART JUNCTION BOX
FUSE/RELAY
LOCATION
FUSE AMP
RATING
PROTECTED
CIRCUITS
