MV-1 PT019021 - Page 148

146 Roadside Emergencies
35 7.5A Not Used
36 5A PATS (R/S)
37 10A Climate Control Head, Door
Actuators, Coolant Control
Valve (R/S)
38 20A Not Used
39 20A Radio Power
40 20A Not Used
41 15A Radio On/Off Sw Illum
(Del/Accy)
42 10A Not Used
43 10A Rear Defrost Relay Coil, Front
Wiper Motor, Relay Coils,
Blower Relay Coil (R/A)
44 10A Not Used
45 5A Not Used
46 7.5A Not Used
47 30A Circuit
Breaker
Power Windows (Del/Accy)
SMART JUNCTION BOX
FUSE/RELAY
LOCATION
FUSE AMP
RATING
PROTECTED
CIRCUITS
48 - Delayed Accy
SMART JUNCTION BOX
FUSE/RELAY
LOCATION
FUSE AMP
RATING
PROTECTED
CIRCUITS
