148 Roadside Emergencies
BATTERY JUNCTION BOX
FUSE/RELAY
LOCATION
FUSE AMP
RATING
PROTECTED
CIRCUITS
1 HC Micro Relay PCM
2 HC Micro Relay Starter Solenoid
3 HC Micro Relay Rear Defrost
4 HC Micro Relay HVAC Blower Motor
5 HC Micro Relay Fuel Pump
6 HC Micro Relay Washer Pump
7–Not Used
8 HC Micro Relay Front Wiper High
9 HC Micro Relay ALC Compressor
10 – Not Used
11 – Not Used
12 40A** Engine Cooling Fan #1
13 30A** Starter Solenoid Relay
14 40A** Run Start Relay
15 40A** Engine Cooling Fan #2
16 40A** Auto Level
Compressor Motor
17 – Not Used
18 30A** Auto Level Exhaust
Va lv e
19 – Not Used
20 – Not Used
21 20A** ABC VBAT 1 Module
(Power Ramp Motor),
Brake Transmission
Shift Interlock
22 – Not Used
23 G8VA relay A/C Clutch
24 G8VA relay Front Wiper Low
25 HC Micro relay Run/Start
26 20A* Washer Pump
27 – Not Used
28 15A* Back Up Lamp
29 10A* A/C Clutch
30 10A* Stoplamp Sw
31 – Not Used
32 40A** Blower Motor
BATTERY JUNCTION BOX
FUSE/RELAY
LOCATION
FUSE AMP
RATING
PROTECTED
CIRCUITS
