33 30A** Rear Defrost
34 – Not Used
35 40A** PCM VPWR (Main)
36 – Not Used
37 – Not Used
38 – Not Used
39 G8VA relay Back Up LP
40 ISO relay Engine Cooling Fan
Hi/Low
41 10A* Auto Level Control
Module
42 – Not Used
43 20A* Fuel Pump (Gas), Tank
Valves (CNG)
44 25A* High Wiper
45 25A* Low Wiper
46 10A* PCM KA Power/Can
Vent/PCM Relay Coil
47 60A** ABS Pump Motor
BATTERY JUNCTION BOX
FUSE/RELAY
LOCATION
FUSE AMP
RATING
PROTECTED
CIRCUITS
48 – Not Used
49 – Not Used
50 – Not Used
51 – Not Used
52 10A* Auto Level Control
R/S
53 10A* ABS Module R/S Feed
54 10A* Fuel Pump Relay
Coil (Gas), Tank Valve
Relay Coil (CNG),
PCM R/S
55 – Not Used
56 – Not Used
57 – Not Used
58 – Not Used
59 – Not Used
60 Mini Diode Start
61 – Not Used
BATTERY JUNCTION BOX
FUSE/RELAY
LOCATION
FUSE AMP
RATING
PROTECTED
CIRCUITS
