150 Roadside Emergencies
62 HC Micro relay Engine Cooling Fan #2
(High)
63 25A** Engine Cooling Fan
#1 & #2 (Low)
64 – Not Used
65 20A** Power Point 2 (IP)
66 20A** Power Point 3
67 20A** Power Point 1 (IP)
68 – Not Used
69 – Not Used
70 – Not Used
71 – Not Used
72 20A** Cigar Ltr
73 – Not Used
74 30A** Power Seat
75 20A* VPWR 1 PCM PWR
(Secondary)
76 20A* VPWR 2 PC Mil
BATTERY JUNCTION BOX
FUSE/RELAY
LOCATION
FUSE AMP
RATING
PROTECTED
CIRCUITS
77 10A* VPWR 3 PCM
non ML
78 15A* VPWR 4 GAS
Ign Coils
79 10A* VPWR 5 Trans
80 – Not Used
81 – Not Used
82 – Not Used
83 Mini Diode Fuel Pump (Gas), Tank
Valves (CNG)
84 – Not Used
85 HC Micro relay Engine Cooling Fan #1
(High)
*Mini fuses **A1S fuses
BATTERY JUNCTION BOX
FUSE/RELAY
LOCATION
FUSE AMP
RATING
PROTECTED
CIRCUITS
