hyperion - TECHNICAL MANUAL
3.1.1 Connector list
CONNECTOR DESCRIPTION
K2 Xaxispowersupply
K3 Yaxispowersupply
K4 Raxis(rotation)powersupply
K7 X limit switch
K9 Y limit switch
K14 Rlimitswitch
K36 Column limit switch
K16 PAN sensor (LVDS cable)
K27 Identication/powersupplyPANsensor
K37 Haxis(ceph)powersupply
K13 H limit switch
K17 CBCT(24V)Flatpanelpowersupply
K19 USB for external port on console
K12 Column potentiometer
K5 Ethernet toward PC (not panel)
KCB4 (CAN2) CAN for Inverter board (column)
K35 Commands (analog signals) for Inverter board (column)
K38 Input12VfromPFC(MAINOFFifmissingpowersupply)(seeDL1)
K23 48V output for CEPH (Csens)
KCB1 (CAN1) CAN for Csens
K22 Input 48V from converter board (see DL10)
KCB2 (CAN1) CAN per converter
K26 Identication/powersupplyCEPHsensor
K15 CEPH sensor (LVDS cable)
K39 12VoutputtowardConsole(ifinversionK38/K39samesymptomasshortcut,seeDL1)
KCB3 (CAN2) CAN for console
K34 Not used
K18 Not used
J12 Not used (debug)
K20 SDCardconnector–onlyforINTERNALUSE
J10/J11 BatterybufferforclockCr2450(3Vlitio)–usedwhenstoringImagesonUSB
