hyperion - TECHNICAL MANUAL
3.2.1 Connector list
CONNECTOR DESCRIPTION
K2 400Vtowardinverterboard(protectedbyPF3-8°fuse)
KCB2 CAN toward Inverter board (97661076)
K11 12V out for MAIN board
K4 Externallampsconnection(clearcontactforexternalrelè)(pin1-2ready,3-4emission)
M2/M3 Line/Neutraltowardmainswitch(orderdoesn’tmatter)
M1 Mainpowersupplyinput(220V/115V)
K5 ConnectorforInternalEmergencybuttonmountedonpatientarm
K7 ConnectorforX-raycommand
K8 Interlock (shortcut if not installed)
K1 ConnectorforInternalEmergencybutton(shortcutifnotinstalled)
K14 Thermicsensoronboardcooler(mountedonfactory,donotdisconnect)
KCB1 Not used
3.2.2 Fuses
PICTURE DESCRIPTION NOTE
PF1 Usointernoscheda,sostituireschedasedan-
neggiato
PF2–MainPowersupplyprotection FUSE 15 AF 250v 6.3X32 115V(cod.97767400)
FUSE 10 AF 250v 6.3X32 230V(cod.61720010)
PF3 – 400V toward inverter board (for
column)
FUSE 8 AF 600VDC 10.3X38 (cod.61720011)
