hyperion - TECHNICAL MANUAL
3.3.1 Connectors list
CONNECTOR DESCRIPTION
K7 5V for Laser
K6 5V for Laser
K8 5V for Laser
K4 Monoblock feedback
M3 Monoblocklamentpowersupply
M1 Monoblock High voltage
K12 48V out for sensor board
KCB2 CAN connection toward GSENS (If mounted)
KCB1 CAN connection CAN from MAIN Board
K11 48V for MAIN board
K14
K3 Primarycollimatormotors(bothXandYonthesameconnector)
K2 PrimarycollimatorXaxis(horizontal)photocell
K1 PrimarycollimatorYaxis(vertical)photocell
K14 Flatpanel Synchronizationsignal(mergewithK18 [24Vpanel powersupply]fromMAIN
board)
K10 Not used
K12 48V out for GSENS board
M2 400Vinfrominverterboard(column),protectedbyF5fuse
