hyperion - TECHNICAL MANUAL
3.4.1 Connectors list
CONNECTOR DESCRIPTION
K11/K14 DisplayTFT
K4 Medium Sagittal Laser
K2 Touch Screen
KAL6 12/48VpowersupplytowardMSENS
KCB2 CAN toward MSENS (if mounted)
K7 Physicalkeyboard
KAL5 12/48VpowersupplyfromMAIN
KCB1 CAN toward MAIN
K12 Not used
K5 Not used
P1 Not used
3.4.2 Diagnostic led
LED COLOUR DEFAULT STATUS FAULT STATUS DESCRIPTION
DL1 (3v3) Green ON OFF Powersupply3.3V
DL2 (12V) Green ON OFF Powersupply12V
DL3 (5V) Green ON OFF Powersupply5V
DL5 (DIAG) Green Blinking ON or OFF CPUstatus,ifDL6isON,num-
berofashesidentiestheerror
code
DL6(ERR) Red OFF ON Generic error
DL7 (ACT) Yellow Blinking ON or OFF CAN communication
DL9 (TOUCH) Green OFF NOT USED
DL4 Green ON OFF 5VCANpowersupply
3.4.3 Dip switches
DIP SWITCH NUM. DESCRIPTION NOTE
SW1 Not used All OFF
SW2 CAN termination Always set to OFF. Set to ON only
MSENS not mounted
