hyperion - TECHNICAL MANUAL
3.1.3 Dip switches
DIP SWITCH NUM. DESCRIPTION Note
SW5 CAN1 channel termination ONwhenCEPHabsente/OFFwhen
CEPH mounted
SW4 CAN2 channel termination AlwaysOFF
SW3 All OFF Not used
SW2(Reboot) RestarttheMAIN(onlythis)
SW1(RESETCONFIG) Pressed for 3sec restore the factory
conguration(IP,Ethernet)
