hyperion - TECHNICAL MANUAL
3.8.1 Connector list
CONNECTOR DESCRIPTION
J9 MainAxisphotocell(CEPHsensorUP/DOWN)
J5 Ear guides potentiometer
J6 Nasion potentiometer
J4 CEPHnasion/earguidessupportpositionsensors
J10 Not used
J15 Notusedinanyconguration
J7 Physicalkeyboard
J14 Main axis motor
J11 48Vpowersupply(CEPHsensorUP/DOWN)
J1 CAN connector
J3 Not used
J2 CANconnector(AlternativetoJ1,usuallynotused)
J12 48Vauxilaryconnector(Nousage)
3.8.2 Diagnostic LEDs
LED COLOUR DEFAULT STATUS FAULT STATUS DESCRIPTION
DL9(zeroA) Yellow X axis photocell (OFF if photo-
cellisfree,ONifsephotocellis
obscured or disconnected)
DL8(zeroB) Yellow Auxiliaryphotocell(OFFifpho-
tocellisfree,ONifsephotocell
is obscured or disconnected)
DL2 (5.0V) Green ON OFF 5Vpowersupply
DL3 (3.3V) Green ON OFF 3.3Vpowersupply
DL6 (CAN ACT) Yellow Blinking ON or OFF CAN communication
DL5(ERR) Red OFF ON Generic error
DL4 (CPU) Green Blinking ON o OFF CPUstatus, OFFduringstand-
by
DL9 (TOUCH) Green OFF NOT USED
DL7 (CAN 5.0V) Green ON OFF 5VCANpowersupply
3.8.3 Dip switches
DIP SWITCH NUM. DESCRIPTION NOTE
SW1 CAN termination AlwaysONforallthecongurations
1 2 3 4
CSENS 0 0 0 1
MSENS 0 0 1 0
SW2 Congurationmodality GSENS 0 0 1 1
