3.3.2 Diagnostic led
LED COLOUR DEFAULT STATUS FAULT STATUS DESCRIPTION
DL7U (400V) Green ON OFF 400Vinput,ONwhendeviceis
notinstandby
DL9 (CPU) Green Blinking OFForalwaysON CPUstatus,OFF duringstand-
by
DL10 (CAN) Green
DL1 (FIL1) Green ON Status of the lament control
circuit. OFF during device boot
andstandby.
DL2 (FIL2) Green ON Status of the lament control
circuit. OFF during device boot
andstandby.
DL3 (INV_OVC) Red OFF ON Over current fault on the inverter
board
DL11(FIL_ERR) Red OFF ON Monoblocklamentcircuiterror
DL_12(KV_ERR) Red OFF ON Monoblock High voltage error
DL4 (AUXP15) Green ON OFF 15V analog
DL5 (AUXM15) Green ON OFF -15V analog
DL6 (INV+15) Green ON OFF +15V driver
DL17 (INV-15) Green ON OFF -15V driver
DL18 (ISO15V) Green ON OFF 15v chopper
DL14 (5V) Green ON OFF 5V logic
DL15 (3V3) Green ON OFF 3.3V logic
DL16 (1V2) Green ON OFF 1.2V logic
DL8 (ISOCAN) Green ON OFF 5V CAN
DL13 (M48V) Green ON OFF 48VtowardMAIN(protectedby
F4)
3.3.3 Dip switches
DIP SWITCH NUM. DESCRIPTION NOTE
SW1 GSENS CAN terminator OFFis GSENS(97661112)mounted,
ON if GSENS absent
3.3.4 Fuses
PICTURE DESCRIPTION NOTE
F5 (cod. 61750021) 2AF 250V 5X20
F4 (cod. 61750022) 5AF 250V 5X20
