hyperion - TECHNICAL MANUAL
4. Error guide
4.1 Firmware messages
4.1.1 0.x Codes - Generic Warnings
Code Message Description/solution
0.1 X-ray button released too soon Hold the X-ray emission button until the end of the procedure
0.2 X-ray button pressed
1) X-ray button was held for too long after the end of ex-
posure (>15s)
2) Reset command sent while button xray button was
pressed
3) Leaving stand-by status while button was pressed
0.3 Emergency stop pressed Release the emergency stop button
0.4
Power board(PFC) does not communicate
with MAIN board
Turn off the unit, check CAN bus connections, wait 30sec
and turn it back on. If the problem persists contact tech sup-
port.
0.5
Console board does not communicate with
MAIN board
0.6
CONVERTER board does not communicate
with MAIN board
0.8
CSENS board does not communicate with
MAIN board
0.9
MSENS board does not communicate with
MAIN board
0.10
GSENS board does not communicate with
MAIN board
0.11
INVERTER board does not communicate
with MAIN board
0.13 Sensor initialization error
Check the removable sensor’s contacts. Unplug the sensor
and plug it back.
0.14 X-Ray start command aborted
1) Check Converter board diagnostic LEDs
2) Verify CAN connector (KCB1) on converter board
0.16 Mount the sensor in PAN position
0.17 Mount the sensor in CEPH position
0.18 Check if CEPH headrest is in correct position
0.19
2D Detector is not recognized (run “Sensor
registration”)
Please serialize the sensor (from unit calibration software
on PC)
0.20 Sensor not calibrated Calibrate the sensor (from unit calibration software on PC)
0.21
Serial number saved on sensor is different
from serial number saved in calibration data
Please serialize the sensor (from unit calibration software
on PC)
0.22 Active interlock switch Check interlock switch (door not closed?)
0.23 Image present in memory
New exposure requested while previous has not been down-
loaded yet
0.24 CBCT started before downloading projection Check connection with PC
0.25 Add CEPH cong
Only at rst startup after CEPH arm installation, call tech
support if persistent.
0.26 CMOS Time and Date Not Set
Set time and date from PC/Check if clock battery on main-
board is dead
0.27 Unit not congured Set conguration from PC
0.28 Unit not calibrated Perform unit calibration
