Myray hyperion X9 - DIAGNOSTIC Leds; Dip Switches

124
EN
hyperion - TECHNICAL MANUAL
3.2.3 DIAGNOSTIC LEDs
LED COLOUR DEFAULT STATUS FAULT STATUS DESCRIPTION
DL7 (12V) Green ON OFF or blinking PFC driver power supply, blin-
king in case of shortcut on inter-
nal 12V.
DL1 Green/Red ON Green OFForONRed 400Vpowersupply,RedifPF3
blown.OFFduringstandby
DL6 (5V CAN) Green ON OFF or blinking CANbuspowersupply
DL8 (VCC) Green ON OFF or blinking PFClogicpowersupply
DL3 (Overvoltage) Red OFF ONRed Fault on 400V
DL5 (OverTemp) Red OFF ONRed Board overheating
DL2 (Status) Green Blinking OFForalwaysON CPU status
DL4 (Error) Red OFF ONRed Generic error on PFC (the num-
ber of ashes of DL2 indicates
the error code )
DL9 (CAN Act) Yellow Lampeggiante OFForalwaysON CANbusactivity
3.2.4 Dip switches
DIP SWITCH NUM. DESCRIPTION NOTE
SW1 CAN termination, always ON for all
thecongurations
SW2 All OFF Not used
