hyperion - TECHNICAL MANUAL
4.1.2 1.x Codes - Errors from MAIN board
Code Message Description/solution
1.2 Error - Reset AXIS X
Reset movement did not complete
1.3 Error - Reset AXIS Y
1.4 Error - Reset AXIS R
1.5 Error - Reset AXIS H
1.6 Error - Moving Axis X
Movement to required position not completed
1.7 Error - Moving Axis Y
1.8 Error - Moving Axis R
1.9 Error - Moving Axis H
1.10 Error - PRJ AXIS X
Error while moving to required position during scan
1.11 Error - PRJ AXIS Y
1.12 Error - PRJ AXIS R
1.13 Error - PRJ AXIS H
1.14 Column DAC error
Replace the mainboard
1.15 Column ADC error
1.16 Column potentiometer error Check potentiometer and its cables/connectors
1.17 Column movement error Check potentiometer and its cables/connectors
1.18 File system mount error Restart device and retry | Replace the mainboard
1.19 File system error Restart device and retry | Replace the mainboard
1.20 Cong le serialization error Restart device and retry
1.21 Cong le de-serialization error Restart device and retry
1.22 Eeprom error Restart device and retry | Replace the mainboard
1.23 Error while loading PRJ from internal memory Restart device and retry | Replace the mainboard
1.24
Error during “move to” command, due to sa-
fety microswitch
Restart device and retry | Replace the mainboard
1.25
Movement not permitted by collision detec-
tion system
Restart device and NNT and retry
1.26
Reset procedure aborted, primary collimator
movement request was rejected
Check primary collimator it is not mechanically blocked and
retry
1.27
CAN queues management error
Restart device and retry | Turn off and back on the unit. If
Converter board is on but not communicating you will get
warning 0.6. If converter is not powered check voltage (400V)
on M2 connector. Check also CAN connector on KCB1.
1.28 Movement start scan error Restart device and retry
1.30 Movement start error on axis X Restart device and retry
1.31 Movement start error on axis Y Restart device and retry
1.32 Movement start error on axis R Restart device and retry
1.33 Movement start error on axis H Restart device and retry
1.34 X Axis not in reset position (± 0.1mm) Restart device and retry
1.35 Y Axis not in reset position (± 0.1mm) Restart device and retry
1.36 R Axis not in reset position (± 0.1°) Restart device and retry
1.37 H Axis not in reset position (± 0.1mm) Restart device and retry
1.38 Position error at start scan Restart device and retry
1.39 Reset position error Restart device and retry
1.40
The console brand does not match the one
set on MAIN
Please update FW to set correct brand
