hyperion - TECHNICAL MANUAL
Code Message Description/solution
1.41 CAN0 diagnostic, 200 busOff count reached
Check cables and terminations on CAN bus (CAN0 – Con-
verter, GSENS, CSENS, Main)
1.42 CAN1 diagnostic, 200 busOff count reached
Check cables and terminations on CAN bus (CAN1 –
PFC,Main, Console, MSENS, Column inverter)
1.43 2D Sensor turning off timeout Check LVDS cable
1.44
Xray button pressed before starting 2D cali-
bration
Release Xray button and retry
1.45 Reset command not accepted Reset command sent during PARKING movement
1.46 Parking command not accepted Parking command sent during RESET movement
1.47 Unable to wake up from idle status
1.48 Unable to set voltage Retry and, if persists, reboot the device
1.49 PFC connection mismatch
PFC board is plugged to a wrong CAN bus connector. Plug it
to the correct connector and restart
1.50 CSENS connection mismatch
CSENS board is plugged to a wrong CAN bus connector.
Plug it to the correct connector and restart
1.51 MSENS connection mismatch
MSENS board is plugged to a wrong CAN bus connector.
Plug it to the correct connector and restart
1.52 GSENS connection mismatch
GSENS board is plugged to a wrong CAN bus connector.
Plug it to the correct connector and restart
1.53 CONVERTER connection mismatch
CONVERTER board is plugged to a wrong CAN bus connec-
tor. Plug it to the correct connector and restart
1.54 KEYBOARD connection mismatch
KEYBOARD board is plugged to a wrong CAN bus connec-
tor. Plug it to the correct connector and restart
1.55 INVERTER connection mismatch
INVERTER board is plugged to a wrong CAN bus connector.
Plug it to the correct connector and restart
1.56 Unable to perform the parking procedure
Check correct movements of ceph sensor slide and detec-
tors carousel
