hyperion - TECHNICAL MANUAL
3.1.2 Diagnostic leds
Kinematic section
LED COLOUR DEFAULT STATUS FAULT STATUS DESCRIPTION
DL20(C-zero) Green OFF H Ceph limit switch (ON with limit
switch or photocell disconnected,
OFF when limit switch not detected)
DL19(R-zero) Green OFF Rlimitswitch(seeabove)
DL18(Y-zero) Green OFF Y limit switch (see above)
DL37(X-zero) Green OFF X limit switch (see above)
DL35 (Motors Enb -
"Motors enable")
Yellow ON ON if motors enabled. OFF when de-
vice is in stand-by status, otherwise
alwaysON.
DL16 (Stop UP) Yellow ON OFF when microswitch limit switch
(TOP) is reached or if the inverter bo-
ard(97661076)notenergizedornot
connected to K35.
DL17 (Stop Down) Yellow ON OFF when microswitch limit switch
(BOTTOM) is reached or if the inver-
ter board (97661076) not energized
or not connected to K35.
Power supply section
LED COLORE STATO NORMALE STATO ERRORE DESCRIZIONE
DL1 Green ON OFF ON if 12V from PFC(97661113) OK.
In case of shortcut on the 12V cir-
cuitfromPFC(K38)DL9/DL6/DL8on
PFCblinkatabout2Hz
DL2 (5V) Green ON OFF Board internal voltage, OFF status
shows a fault condition.
DL3 (3.3V) Green ON OFF As above
DL4 (2.6V) Green ON OFF As above
DL5 (1.2V) Green ON OFF As above
DL31 (FP1 ON) Green ON OFF FlatPanelPowersupplystatus
DL33 (24V CBCT
panel)
Green ON OFF ONifconverter48V/24VforFlatPa-
nelonconverterboardisok,OFFdu-
ringstand-byorfault
DL26 (12V aux) Green ON OFF
DL11 Green ON OFF CAN bus power supply(both bran-
ches)–IfOFFfailureonMAIN,orlow
12Vvoltage,checkvoltageonK38
