hyperion - TECHNICAL MANUAL
PAN/CEPH sensor section
LED COLOUR DEFAULT STATUS FAULT STATUS DESCRIPTION
DL29 (PAN ON) Green ON during sensor ini-
tialization
Sensor powered (synchronized
withGreenledonsensor,during
initialization)
DL12 (PAN LOCK) Green ON during sensor ini-
tialization
Reception OK (synchronized
withYellowledonsensor,during
initialization)
DL40 (PAN IN) Green ON Sensor detected (placed in the
slot)
DL30 (CEPH ON) Green ON during sensor ini-
tialization
Sensor powered (synchronized
withGreenledonsensor,during
initialization)
DL13 (CEPH LOCK) Green ON during sensor ini-
tialization
Reception OK (synchronized
withYellowledonsensor,during
initialization)
DL41 (CEPH IN) Green ON Sensor detected (placed in the
slot)
DL8 (DIAG2) Green - - FPGA - not diagnostic
DL9 (DIAG1) Green - - FPGA - not diagnostic
DL21 (DIAG3) Green - - FPGA - not diagnostic
CAN BUS section
LED COLOUR DEFAULT STATUS FAULT STATUS DESCRIPTION
DL14 (CAN1 ACT) Yellow Blinking AlwaysONoralways
OFF
If always ON fault on the CAN
channel,ifalwaysOFFfaulton
the MAIN
DL15 (CAN2 ACT) Yellow Blinking AlwaysONoralways
OFF
If always ON fault on the CAN
channel,ifalwaysOFFfaulton
the MAIN
Other LEDs
LED COLOUR DEFAULT STATUS FAULT STATUS DESCRIPTION
DL23 (USB ON) Green ON with connected
USB
ON with connected USB
DL34(USBERR) Red OFF ON ON when fault on the USB po-
wersupply(overload)
DL38 (ACT) Yellow Blinking - Ethernet
DL39 (LNK) Green ON OFF Ethernet
DL6 (CPU) Yellow
DL7(ERR) Red
DL25 (SD ON) Green SDcardpowersupply(Internal
use)
DL36(Reset) Green OFF ON when pressing SW2 (reset)
