hyperion - TECHNICAL MANUAL
4.1.6 7.x Codes - Errors from MSENS board (chinrest)
Code Message Description/solution
7.1 Movement timeout Check chinrest slide is not mechanically blocked
7.2 Move command not performed Check chinrest slide is not mechanically blocked
7.3 Incoherent status Restart device and retry
7.4
Generic error (failed to set status to IDLE or
UPDATE. Movement in progress?)
FW error on MSENS or MAIN board
7.5 Invalid parameter or wrong command FW error on MSENS or MAIN board
7.6 Invalid position FW error on MSENS or MAIN board
7.7 Axis reset timeout Motor not moving, check motor
7.8 Potentiometer error Check potentiometers connectors
7.9 Aborted command Restart device and retry
7.10 Incoherent axis movement Restart device and retry
4.1.7 8.x Codes - Errors from GSENS board (detectors carousel)
Code Message Description/solution
8.1 Movement timeout
Check sensor carousel is not mechanically blocked and opti-
cal switches are ok
8.2 Move command not performed
Check sensor carousel is not mechanically blocked and opti-
cal switches are ok
8.3 Incoherent status Restart device and retry
8.4
Generic error (failed to set status to IDLE or
UPDATE. Movement in progress?)
FW error on GSENS or MAIN board
8.5 Invalid parameter or wrong command FW error on GSENS or MAIN board
8.6 nvalid position FW error on GSENS or MAIN board
8.7 Axis reset timeout Motor not moving, check motor
8.8 Potentiometer error Check potentiometers connectors
8.9 Aborted command Restart device and retry
8.10 Incoherent axis movement Restart device and retry
