hyperion - TECHNICAL MANUAL
4.1.4 4.x Codes - Errors from CONVERTER board
Code Message Description/solution
4.30 Interrupted lament If persistent replace converter or x-ray head
4.31 Excessive anodic tension If persistent replace x-ray head
4.32 Unbalanced anodic tension If persistent replace x-ray head
4.33 Excessive anodica tension
Perform tube head calibration, If persistent replace x-ray
head
4.34 Excessive inverter current If persistent replace converter board or xray generator.
4.35 Inverter short circuit If persistent replace converter board
4.36 Actual emission time longer than set time FW error on main or converter
4.37 Watchdog action FW error on main or converter
4.39 Interrupted exposure
Xray button released, open interlock or emergency button
pressed
4.40 Y axis primary collimator movement error
Check primary collimator it is not mechanically blocked and
retry
4.41 X axis primary collimator movement error
Check primary collimator it is not mechanically blocked and
retry
4.42 Y axis primary collimator movement error Optical switch not reached during reset. Check axis motor.
4.43 X axis primary collimator movement error Optical switch not reached during reset. Check axis motor.
4.44 Stato Scheda CONVERTER non coerente FW error on main or converter
4.45 Unhandled error Restart device and retry
4.1.5 6.x Codes - Errors from CSENS board
Code Message Description/solution
6.1 Movement timeout Check sensor slide is not mechanically blocked
6.2 Move command not performed Check sensor slide is not mechanically blocked
6.3 Incoherent status Restart device and retry
6.4
Generic error (failed to set status to IDLE or
UPDATE. Movement in progress?)
FW error on CSENS or MAIN board
6.5 Invalid parameter or wrong command FW error on CSENS or MAIN board
6.6 Invalid position FW error on CSENS or MAIN board
6.7 Axis reset timeout Motor not moving, check motor
6.8 Potentiometer error Check potentiometers connectors
6.9 Aborted command Restart device and retry
6.10 Incoherent axis movement Restart device and retry
