Minitower Repair 6-5
4. Slide the bottom access cover toward the front of the system releasing the tabs
from the cutouts in the bottom of the chassis.
Figure Section 6-5 Minitower Bottom Access Cover
Expansion Board Removal
Remove any installed expansion board(s) using Figure Section 6-7 and the following steps.
1. Remove the top cover as previously described.
2. Disconnect any cables leading from the expansion board(s).
3. Remove the screw from the expansion slot bracket (see Figure Section 6-7).
Figure Section 6-7 Expansion Slot Screw
1 of 4 Tabs
Cutout
Bottom Access
Cover
Access Cover
Screw
1 of 5 Expansion
Slot Screws
