6-12 Minitower Repair
5 1/4-Inch Device Removal
Remove a 5 1/4-inch device from the 5 1/4-inch device cage as follows.
1. Remove the top cover, front panel, and 5 1/4-inch device cage as previously de-
scribed.
2. Remove the four 5 1/4-inch hard disk drive screws; two on each side (see
Figure Section 6-12).
3. Remove the device out of the 5 1/4-inch device cage.
Figure Section 6-12 5 1/4-Inch Device Screws
2 of 4 Device
Screws
Device
Cage
