NEC POWERMATE P60D - Diskette Drive Bracket Screws

6-16 Minitower Repair
3. Remove the three 3 1/2-inch diskette drive bracket screws shown in Figure Sec-
tion 6-22.
Figure Section 6-22 Diskette Drive Bracket Screws
4. Slide the 3 1/2-inch diskette drive with bracket out of the system unit.
5. Remove the four 3 1/2-inch diskette drive screws; two on each side (see
Figure Section 6-24).
6. Remove diskette the drive out from the bracket.
Figure Section 6-24 Diskette Drive Screws
3 1/2-Inch
Diskette Drive
Bracket Screws
2 of 4
Screws
3 1/2-Inch Diskette
Drive Bracket
