3-32 Options
2. Remove the five device cage screws shown in Figure Section 3-38.
Figure Section 3-38 Removing the Device Cage Screws
3. Pull the device cage out of the chassis. If there is a device already installed in the
cage, tag and unplug the power and signal cables.
Continue to “Minitower 5 1/4-Inch Device Placement.”
Screws
Screws
