Minitower Repair 6-11
5 1/4-Inch Device Cage Removal
Remove the 5 1/4-inch device cage from the system unit as follows.
1. Remove the top cover, front panel as previously described.
2. Remove the five device cage screws shown in Figure Section 6-10, holding the
cage to the chassis. If there is a device installed in the cage, label and unplug the
power and signal cables.
3. Pull the device cage out of the chassis.
Figure Section 6-10 Removing the Device Cage Screws
Screws
Screws
