3-42 Options
3. Connect one end of the power cord to the monitor. Plug the other end into the
AC wall outlet.
NOTE: Figure shows the monitor connection in
the minitower orientation. If the system unit in
the figure were in the desktop position, attach
the monitor to the same connector.
Figure Section 3-50 Monitor Connections
Voltage
Selector
Switch
Selector
Switch
Voltage
Screws
Monitor
Signal Cable
Monitor Power
Cable
Monitor
System Unit
Power Cable
