2-6 Setup and Operation
2. Connect the keyboard and mouse cables to the back of the system unit (see
Figure Section 2-8).
3. Connect the monitor and any other peripherals to the rear panel (see Figure Sec-
tion 2-8). Detailed monitor connections are given in Section 3, Options.
Figure Section 2-8 Minitower Peripheral Connections
4. Press the power button to power-on the system (see Figure Section 2-10). The
user lamps and reset button are also identified in the figure.
Figure Section 2-10 Minitower Indicators, Reset Button, and Power Button
Keyboard Port
Mouse Port
Serial Port 1
Serial Port 2
Parallel Printer
Port
15-Pin VGA
Monitor
Connector
Expansion Slot
Covers
Power Button
Power Lamp
Reset Button
Hard Disk Drive
Busy Lamp
