1.3 Basic Features
Parameter
Description
Physical features
Dimensions: (30.0±0.1) mm × (28.0±0.1) mm × (2.8±0.2) mm
Package: 100-pin LGA
Weight: around 5.3g
Temperature
ranges
Operating: -35°C to +75°C
Extended: -40°C to +85°C
Storage: -45°C to +90°C
Operating voltage
VBAT: 3.3V to 4.3V, TYP: 3.8V
Current
Flight mode
1.24mA
Sleep Mode
GSM DRX=6: 2.2mA
GSM DRX=9: 1.45mA
WCDMA DRX=2: 2.64mA
WCDMA DRX=9: 1.54mA
LTE (Paging Cycle 320ms): 6.5mA
LTE (Paging Cycle 2.56s): 1.67mA
Active
VBAT: 2A Max
Processor
ARM Cortex-A7 processor, 1.3 GHz main frequency
Memory
ROM+RAM:
⚫ 2Gb+1Gb
⚫ 4Gb+2Gb
Operating Bands
See Table 1-1.
Wireless rate
GPRS: Max 85.6 Kbps(DL) / Max 85.6 Kbps(UL)
EDGE: Max 236.8Kbps(DL) / Max 236.8Kbps(UL)
WCDMA: DC-HSPA+, Max 42Mbps (DL)/Max 5.76Mbps (UL)
FDD-LTE: non-CA cat4, Max 150 Mbps(DL)/Max 50 Mbps (UL)
Transmit power
GSM850: (33dBm±2dB) (Power Class 4)
PCS1900: (30dBm±2dB) (Power Class 1)
EDGE 850MHz: (27dBm±3dB) (Power Class E2)
EDGE1900MHz: (26dBm±3dB) (Power Class E2)
UMTS: (24dBm+1/-3dB) (Power Class 3)
LTE: (23dBm±2dB) (Power Class 3)
