Figure 3-49 Recommended RF PCB design 1
3.5.2 ANT_GNSS Interface
GPS Impedance Control
ANT_GNSS (92) is the GNSS RF interface of N75, which requires a characteristic impedance of 50Ω.
Figure 3-50 shows the GNSS structure inside the module.
Figure 3-50 GNSS RF structure
ANT_GNSS
WTR GNSS
Interface
N75 module
SAW
