4 Electric Feature and Reliability
This chapter describes the electric features and reliability of N75, including current and voltage of each
power pin, operating and storage temperature ranges, and ESD protection features.
4.1 Electric Features
Table 4-1 Electric features
Parameter
Minimum Value
Typical Value
Maximum Value
VBAT
V
in
3.3V
3.8V
4.3V
I
in
/
/
2A
If the voltage is lower than threshold, the module might fail to start. If the voltage is higher than
threshold or there is a voltage burst during the startup, the module might be damaged permanently.
If you use LDO or DC-DC to supply power for the module, ensure that it outputs at least 2 A current.
When the module works at maximum power in GSM mode, the peak current might reach 2A. Add a
large capacitor to the VBAT pin to enhance the capability to output continuous current and avoid
voltage drop.
Table 4-2 Current consumption of N75
Variant
Status
Test Conditions
Test Result (Typ)
Unit
CN
Power OFF
Shut down the module.
20
μA
Sleep Mode
GSM850 DRX=2
2.81
mA
GSM850 DRX=9
1.45
mA
WCDMA DRX=2
2.64
mA
LTE Paying cycle = 320ms
6.5
mA
LTE Paying cycle = 640ms
3.8
mA
LTE Paying cycle = 1.28s
2.4
mA
LTE Paying cycle = 2.56s
1.67
mA
Active Mode
GSM850 Voice Call PCL=5
248
mA
