N75
Hardware User Guide
Copyright © Neoway Technology Co., Ltd
22
Figure 3-10 Reset controlled by button
N75
module
RESET_N
S1
1 kΩ
ESD
R1
Figure 3-11 Reset circuit with triode separating
R317
VDD_1P8
VCC_2P8/3P0/3P3
N75 module
RESET_N
Q304
4.7kΩ
R318
4.7kΩ
Figure 3-12 shows the reset timing of N75.
Figure 3-12 Reset timing of N75
VBAT
RESET_N
Inactive
Active
USB
All Interfaces
V
L
<0.6V
t 1s
