Neoway N75 - Page 70

N75
Hardware User Guide
Copyright © Neoway Technology Co., Ltd
60
46
UART5_TXD
GPIO_8
SPI_MOSI_BLSP5
Y
47
UART5_RXD
GPIO_9
SPI_MISO_BLSP5
Y
48
WCI_LTE_RXD/USB_
BOOT
GPIO_37
5
Y
50
WCI_LTE_TXD
GPIO_36
7
51
BT_WAKEUP_HOST
GPIO_10
UART5_CTS
SPI_CS_N_BLSP5
I2C_SDA_BLSP5
52
BT_WAKEUP_SLAVE
GPIO_11
UART5_RTS
SPI_CLK_BLSP5
I2C_SCL_BLSP5
Y
54
WLAN_SDIO_CMD
GPIO_17
UART4_RXD
SPI_MISO_BLSP4
Y
55
WLAN_SDIO_CLK
GPIO_16
UART4_TXD
SPI_MOSI_BLSP4
Y
56
WLAN_SDIO_DATA0
GPIO_15
UART1_RTS
I2C_SCL_BLSP1
SPI_CLK_BLSP1
57
WLAN_SDIO_DATA1
GPIO_14
UART1_CTS
I2C_SDA_BLSP1
SPI_CS_N_BLSP1
GP_CLK_1B
58
WLAN_SDIO_DATA2
GPIO_13
UART1_RXD
SPI_MISO_BLSP1
GP_CLK_3B
Y
59
WLAN_SDIO_DATA3
GPIO_12
UART1_TXD
SPI_MOSI_BLSP1
GP_CLK_2B
Y
60
WAKE_ON_WIRELES
S
GPIO_59
Y
62
WLAN_EN
GPIO_38
7
Y
65
GPIO_79
GPIO_79
7
I2S_2_WS
BT_PCM_SYNC
Y
66
GPIO_78
GPIO_78
7
I2S_2_SCLK
BT_PCM_CLK
67
GPIO_77
GPIO_77
I2S_2_D1
BT_PCM_DOUT
5
Pull up this pin to high level before the module is started, and the module enter USB_BOOT mode.
