NetApp AltaVault AVA400 - Viewing the interface counters report

138 NetApp AltaVault Cloud Integrated Storage Administration Guide
Beta Draft
Viewing reports and logs Viewing the interface counters report
 How much memory is being used?
 What is the average and peak number of memory pages swapped?
To view the Memory Paging report
1. Choose Reports > Memory Paging.
2. Use the controls in the control panel to customize the report as described in this table.
Viewing the interface counters report
The Interface Statistics report displays information for each AltaVault interface, such as the interface name, its IP
address, the Ethernet MAC address settings, the link settings, and the number of packets received and transmitted by
the interface.
The Interface Statistics report includes the following statistics.
The Interface Statistics report answers the following questions:
Control Description
5m 1h 1d 1w All Select one of the following report time intervals to filter the display:
• 5m - Displays five minutes of data.
• 1h - Displays one hour of data.
• 1d - Displays one day of data.
• 1w - Displays one week of data.
• All - Displays all data available for the past 30 days.
To type a custom time interval, enter the start time and end time (using the format YYYY/MM/DD
HH:MM:SS) in the text field.
You can view the newest data and see data points as they are added to the chart dynamically.
Show newest data Click this option to display only the latest data available. The latest data available depends on the
time interval that you specify. For example, if 1h is the specified time interval, then clicking Show
newest data displays the last 60 minutes of data.
Field Description
Interface Name of the AltaVault
interface.
IP IP address of the network interface.
Ethernet The MAC address information for the interface. The speed can be Auto,
1000, 100, or 10. The default value is Auto.
Link Parameter that indicates whether there is an active connection plugged into
the interface. Displays true if the interface is connected; otherwise, it
displays false.
Receive Packets Number of packets received by the interface. It also provides details such
as the number of packets discarded, packet errors, packet overruns, packet
frames, and packets multicast.
Transmit Packets Number of packets transmitted by the interface. It also provides details
such as the number of packets discarded, packet errors, packet overruns,
packet frames, and packets multicast.
