CHAPTER 15 System components AVA-400, AVA-
800
This section provides system specifications for the NetApp AltaVault appliance. It includes the following sections:
 “AltaVault appliance components” on page 183
 “Using LEDs to check the status of the system” on page 185
 “Field replaceable units” on page 187
 “Fan modules and their LEDs” on page 188
 “Power supplies and their LEDs” on page 191
 “Controller components and their LEDs” on page 193
 “Internal FRUs” on page 196
For a detailed list of system hardware components and specifications, see NetApp Hardware Universe.
AltaVault appliance components
The AltaVault AVA400 or AVA800 chassis contains the following components:
 AVA400 or AVA800 controller
 Front panel with Power, Warning, and controller Activity LEDs
 Two field-replaceable 1300W, 100-240V AC auto-ranging, plug-in power supply units
 Three field-replaceable high-speed fan modules
 Rack mounting kit for standard racks
The AV10S disk shelf contains:
 Up to 24 hot-swappable 4TB (AVA400) or 6TB (AVA800) disk drives
 A front panel with Power, Warning, Activity, and Shelf ID LEDs
 Two field-replaceable 530W, 100-240V AC auto-ranging, plug-in power supply units
 6Gb/s SAS IOMs for connectivity to the controller
