NETGEAR GSM7228PS Software Administration Manual

168 | Chapter 11. CoS Queuing
ProSafe 7000 Managed Switch Release 8.0.3
2. Select the Global radio button.
3. In the Global Trust Mode list, select trust dot1p.
4. Click Apply to save the settings.
Show classofservice IP-Precedence Mapping
The example is shown as CLI commands and as a Web interface procedure.
CLI: Show classofservice IP-Precedence Mapping
(Netgear Switch) #show classofservice ip-precedence-mapping
IP Precedence Traffic Class
------------- -------------
0 1
1 0
2 0
3 1
4 2
5 2
6 3
7 3
Web Interface: Show classofservice ip-precedence Mapping
1. Select QoS > CoS > Advanced > IP Precedence Queue Mapping. A screen similar to
the following displays.
2. In the Interface list, select All.
The global IP precedence to queue mapping is displayed.
3. In the Interface list, select the specific interface (such as 1/0/1).
