152 | Chapter 10. ACLs
ProSafe 7000 Managed Switch Release 8.0.3
e. Click Apply. A screen similar to the following displays.
ACL Redirect
This feature redirects a specified traffic stream to a specified interface.
GSM73xxS
1/0/1
Workstation
Workstation
Web server
Other network
1/0/19
HTTP packets
Other packets
Figure 18. ACL Redirect
CLI: Redirect a Traffic Stream
The script in this section shows how to redirect an HTTP traffic stream received in an
interface to the specified interface. This example redirects the HTTP traffic stream received in
port 1/0/1 to port 1/0/19.
