User Manual MX Series Voice Gateway
18 New Rock Technologies, Inc.
Table 1-5 Indicator Status of HX4E
The device is powered off or a power supply fault occurred
The WAN interface failed to acquire the IP address. Possibly the WAN
interface is not connected to a network cable, the WAN interface
address failed to be acquired by DHCP, the IP addresses are conflicted,
and the PPPoE dialing failed.
The device is starting or the KUPDATE is upgrading.
Registration is successful.
Blinking
alternatively
between red and
green
Registration has not started.
A WAN connection is established without any service flow.
A WAN connection is established with service flow.
WAN interface is disconnected.
A link is connected without any service flow.
A service flow is being transmitted.
Off-hook or call established
The port is in idle status
1.3.2 MX8A
The MX8A adopts a compact metal structural design. It can be placed on a desk or installed in a standard
communications cabinet and provides eight analog ports. MX8A supports the following types of
configuration.
Table 1-6 Configuration Combination of MX8A
To Next Page
