New Rock Technologies MX series User Manual

User Manual MX Series Voice Gateway
44 New Rock Technologies, Inc.
Name
Description
Subdomain
name
This domain name will be used in INVITE messages. If it is not set here, the gateways will use the
IP address or domain name of the proxy server as the user-agent domain name. It has no default
value.
Registrar mode
The gateway supports three registration schemes:
 Per line (default): authenticate and register per line.
 Per gateway: authenticate and register per gateway.
 Per line/GW auth: Enable registration per line. Use the number configuration per line. Use the
global account and password in authentication.
User name
Configure the user name as part of the account for registration. It has no default value.
Note: If Per gateway or Per line/GW Auth is selected for Registrar mode, the user name must be
entered here. If per line is selected the user name should be set on “Line> Feature” page (Refer to
2.3.2 Subscriber Line Features).
Registrar
password
Password as part of account information is used for authentication by platform. It has no default
value. It can be formed with either numbers or characters, and is case sensitive.
Note: If Per gateway or Per Line/GW Auth is selected for Registrar mode, the password must be
entered here. If Per line is selected the password should be set on “Line>Feature” page (Refer to
2.3.2 Subscriber Line Features).
Registration
expiration
Valid time of SIP re-registration in seconds. Its default value is 600.
2.2.6 High Availability
After login, click Basic>SIP to open the configuration interface.
For details, see High Availability Configuration Guide.
Figure 2-25 High Availability Configuration Interface
Table 2-8 Parameters
Name
Description
Mode
High availability can be configured as Primary-Standby, Active-Standby or Load
Balancing mode.
Primary-Standby mode
