Table 1-28 Meanings of MX120G Indicators
Indicator
Status
Description
PWR
(red, green)
Steady green
The power supply is working.
Off
No power supply.
Steady red
The power supply is abnormal.
STU
(red, green)
Blinking green
The device is running.
Steady red
The device is starting.
Blinking red
The device is under diagnosis.
Off
The device is locked.
ALM
(red, green)
Off
No alarm
Blinking red
The alarms indicated by the blinking alphabetic messages C/E/T on LED dot-
matrix are generated.
Steady red
The alarms indicated by the blinking alphabetic messages D on LED dot-
matrix are generated.
ETH1/ETH2
(green)
Steady green
(right side)
The transmission rate is 1000 Mbps.
Off
(right side)
The transmission rate is 10/100 Mbps.
Steady green
(left side)
A physical connection is established without any traffic.
Blinking green
(left side)
A physical connection is established with traffic.
Off
(left side)
No connection is established.
USB
(green)
Steady green
The USB device is detected.
Off
The USB device is not detected.
Table 1-29 MX120GSystem Operation State
Glittery letter
Status meaning
Blinking with C
IP address conflicts
Blinking with D
The severe starting failure needs to address by your dealer
Blinking with E
Network failure
Blinking with P
Software upgrading
Blinking with T
App exited (The device cannot be used normally)
