New Rock Technologies MX series User Manual

User Manual MX Series Voice Gateway
26 New Rock Technologies, Inc.
Figure 1-11 Schematic Diagram of MX60E Subscriber Line Connection
Figure 1-12 MX60E Back Panel-AC
Table 1-19 Description of MX60E Back Panel
Item
Description
Ground pole
PWR/STU/ALM
Indicator, see Table 1-20 for description
USB
USB interface
CON
Configuration interface (CON), used for local management and debugging
ETH1/ETH2
Two 10/100 Mbps Ethernet ports (RJ45). They share one IP address, which by default is
192.168.2.240, and you can change it on Basic > Network page.
AC power socket, 100-240 VAC voltage input.
