User Manual MX Series Voice Gateway
68 New Rock Technologies, Inc.
For details of Source and Number, see Table 2-20.
For details of Number Transformation and Routing Destination, see Table 2-21 and Table 2-22
respectively.
Table 2-20 Routing Table Format
There are three types of source: IP, FXS (Phone/fax) and FXO (Line).
The IP indicates any IP addresses. IP [xxx.xxx.xxx.xxx] indicates a specific address. IP
[xxx.xxx.xxx.xxx:port] indicates a specific IP address and a specific port number.
The FXS or FXO indicates any FXS or FXO port. FXS1, FXO2, FXS [1-2], or similar indicates a
specific port.
Specify a called party number.
You can specify a calling party number in the form of CPN + number.
The number may be denoted with digits 0-9, "*", ".", "#", " x ", etc., and follows the format of the
dialing rules.
Here are a few ways you can format the number:
Designate a specific number: eg.114, or 61202700
Designate a number matching a prefix: such as 61xxxxxx.
Specify a number scope. For example, 268[0-1, 3-9] specifies any 4-digit number starting with 268
and followed by a digit between 0-1or 3-9
Table 2-21 Number Transformations
Keep number. A positive digit following KEEP indicates the number of digits at the beginning of
the sequence that is kept; a negative digit indicates numbers of digits at the end of the sequence
that is kept.
Example: FXS 02161202700 KEEP -8
Keep the last 8 digits of the called number 02161202700 for calls from FXS. The transformed
called number is 61202700.
Remove number. A positive digit following REMOVE means to remove the number of digits at
the beginning of the sequence; a negative number means to remove the number of digits at the
end of the sequence.
For example: FXS 021 REMOVE 3
Remove 021 of the called number beginning with 021 for calls from FXS.
Add prefix or suffix to number. If the number following ADD is positive, it is a prefix; if it is
negative, it is a suffix.
Example 1:
FXS1 CPNX ADD 021
FXS2 CPNX ADD 010
Add 021 in front of calling numbers for calls from FXS port 1; add 010 in front of calling
numbers for calls from FXS port 2.
Example 2: FXS CPN6120 ADD -8888
Add 8888 at the end of the calling number starting with 6120 for calls from an FXS (Phone/fax)
port.
Number replacement. The replacing number follows REPLACE.
Example: FXS CPN88 REPLACE 2682000
Replace the calling number beginning with 88 for calls from FXS port with 2682000.
